Narrow aisle articulated 2 ton electric Forklift truck with 7m lifting height
Features
1.AC power lifting and driving
2.Works in very narrow aisles
3.2000kg load capacity
4.Lifts to height of 7m
5.Easy battery change
6.Side shift
7.Loads like a counterbalance
Specifications of articulated 2 ton electric Forklift truck
| | Description | Electric |
| 1 | Lift Height mm | 4750 | 7050 |
| 2 | Free Lift mm | 1536 | 2346 |
| 3 | Closed Height mm | 2398 | 3298 |
| 4 | Extended Height mm | 5163 | 7913 |
| 5 | Mast Range mm | 4300-9050 | 7050-12400 |
| 6 | Overall Length mm | 2780 |
| 7 | Ground Clearance mm | 50 |
| 8 | Overhead Guard height mm | 2270 |
| 9 | Chassis Width Rear mm | 1220 | 1400 |
| 10 | Chassis Width Front mm | 980 |
| 11 | Load Centre mm | 500 |
| 12 | Wheel Base mm | 1735 |
| 13 | Seat Height mm | 1220 |
| 14 | Mast Tilt(back/fwd) ° | 3/1 |
| 15 | Capacity kg | 2000 |
| 16 | Ground Speed km/h | 16 |
| 17 | Lift Speed (Laden/unladen) m/s | 0.4/0.5 |
| 18 | Front Tyre size mm | 412*174 |
| 19 | Rear Tyre size mm | 457*150 |
| 20 | Gradeability (Laden/unladen) % | 12/15 |
| 21 | Battery Voltage/Capacity/Engine V/Ah | 48V/775/930Ah |
| 22 | Weight of Truck less battery kg | 5310 |
| 23 | Weight of Truck including the battery kg | 6900 |
| 24 | Standard Color | Yellow/Grey/Red |
| 25 | Seat | KAB |
| 26 | Drive Type | 19.5kw AC Traction motor |
Articulated 2 ton electric Forklift truck
About us
LTMG Machinery Group Co.,Ltd is a leading and professional supplier of Earth moving Equipment, Material Handing Equipment and Quarry Equipment in China.
After 16 years growing, now LTMG has more than 3000 staffs, which 230 engineers and technical researchers. So far have more than 50 exclusive distributors in the world and export to over 100 countries and regions in European, America, Mideast, Asia,Africa etc also OEM service to our clients.
After-sale service
All the products of LTMG supplied with 1 year or 2000 working hours (which occurs first) period quality warranty.
If the machine have any problem within the warranty time, but not caused by man-made, we will send you spare parts for free.
Detail clauses and policies please see to our website and product's quality certificate.
